Home /NBS-2500 Benchtop Blast Cabinet — 25 Gallon Siphon
NBS-2500 Benchtop Blast Cabinet — 25 Gallon Siphon

National Blast Supply

NBS-2500 Benchtop Blast Cabinet — 25 Gallon Siphon

MPN: NBS-2500

$449.99 $599.99
Direct Shipment from Manufacturer
Professional Benchtop Blast Cabinet for Small Parts & Precision Work The NBS-2500 is a compact yet powerful 25-gallon benchtop blast cabinet designed for automotive shops, jewelers, gunsmiths, and hobbyists who need professional-grade surface preparation in a space-saving footprint.
Free shipping on orders over $2,500
Manufacturer warranty included
Ships in 3-5 business days
Questions? (307) 832-5565
Accepted Payment Methods:
Shipping Policy | Return Policy | Warranty Info

Professional Benchtop Blast Cabinet for Small Parts & Precision Work

The NBS-2500 is a compact yet powerful 25-gallon benchtop blast cabinet designed for automotive shops, jewelers, gunsmiths, and hobbyists who need professional-grade surface preparation in a space-saving footprint. Built with 16-gauge welded steel construction and a reinforced viewing window, this cabinet delivers consistent blasting performance for small to medium parts.

Key Features

  • 25-gallon capacity with siphon-feed blasting system
  • 16-gauge welded steel construction with durable powder coat finish
  • Large tempered glass viewing window with replaceable protective film
  • Built-in fluorescent work light for maximum visibility
  • Two heavy-duty rubber glove ports (8" diameter)
  • Includes blasting gun with 4 ceramic nozzle tips (4mm, 5mm, 6mm, 7mm)
  • Bottom-mounted media hopper with gravity-feed reclaim
  • Rear-mounted 2.5" dust port for external dust collector connection
  • Air regulator and pressure gauge included

Technical Specifications

Specification Value
Cabinet Capacity 25 Gallons
Work Area (Interior) 24" W x 18" D x 18" H
Overall Dimensions 30" W x 22" D x 28" H
Operating Pressure 40–120 PSI
Air Requirement (CFM) 5–15 CFM @ 80 PSI
Construction 16-Gauge Welded Steel
Glove Port Size 8" Diameter (2 ports)
Dust Port 2.5" Rear-Mounted
Nozzles Included 4 Ceramic Tips (4mm, 5mm, 6mm, 7mm)
Weight 68 lbs
Shipping Weight 82 lbs

Compatible Media

Glass bead, aluminum oxide, silicon carbide, crushed walnut shell, plastic media, soda (sodium bicarbonate). Not recommended for steel grit or steel shot at this cabinet size.

Recommended Air Compressor

Minimum 3 HP compressor with 10+ gallon tank delivering 10 CFM @ 90 PSI for continuous operation.

Applications

Small automotive parts, brake calipers, carburetors, jewelry, firearms, hand tools, small castings, electronic enclosures, and precision components requiring controlled surface preparation.

Shipping & Delivery

National Blast Supply offers free shipping on all orders over $2,500 within the contiguous United States.

Order Processing

3-5 business days handling time

In Transit

5-7 business days shipping via freight carrier

Total Estimated Delivery

8-10 business days from time of order

Depending on seasonality and availability, shipping times may vary. You will receive tracking information once your order has shipped. For questions about shipping to your area, please contact us at (307) 832-5565 or sales@nationalblastsupply.com.

Warranty & Returns

All products sold by National Blast Supply carry the full manufacturer warranty. Warranty terms vary by manufacturer and product. Please contact us for specific warranty details on this item.

Defective or Damaged Products

If you receive a defective or damaged product, please contact us within 48 hours of delivery at (307) 832-5565 or sales@nationalblastsupply.com. We will work with the manufacturer to resolve the issue promptly.

Returns

Returns of unused, undamaged products may be accepted within 30 days of delivery. A restocking fee may apply. Please contact us before returning any item. For full details, see our Refund & Return Policy.

Questions About This Product?

Our equipment specialists are happy to help you determine if this product is right for your application.

Call Us (307) 832-5565

Monday - Friday, 8:00 AM - 5:00 PM MST

Email Us sales@nationalblastsupply.com

We respond within 24-48 hours on business days

We can also provide custom quotes for bulk orders or special configurations.

Professional Benchtop Blast Cabinet for Small Parts & Precision Work

The NBS-2500 is a compact yet powerful 25-gallon benchtop blast cabinet designed for automotive shops, jewelers, gunsmiths, and hobbyists who need professional-grade surface preparation in a space-saving footprint. Built with 16-gauge welded steel construction and a reinforced viewing window, this cabinet delivers consistent blasting performance for small to medium parts.

Key Features

  • 25-gallon capacity with siphon-feed blasting system
  • 16-gauge welded steel construction with durable powder coat finish
  • Large tempered glass viewing window with replaceable protective film
  • Built-in fluorescent work light for maximum visibility
  • Two heavy-duty rubber glove ports (8" diameter)
  • Includes blasting gun with 4 ceramic nozzle tips (4mm, 5mm, 6mm, 7mm)
  • Bottom-mounted media hopper with gravity-feed reclaim
  • Rear-mounted 2.5" dust port for external dust collector connection
  • Air regulator and pressure gauge included

Technical Specifications

Specification Value
Cabinet Capacity 25 Gallons
Work Area (Interior) 24" W x 18" D x 18" H
Overall Dimensions 30" W x 22" D x 28" H
Operating Pressure 40–120 PSI
Air Requirement (CFM) 5–15 CFM @ 80 PSI
Construction 16-Gauge Welded Steel
Glove Port Size 8" Diameter (2 ports)
Dust Port 2.5" Rear-Mounted
Nozzles Included 4 Ceramic Tips (4mm, 5mm, 6mm, 7mm)
Weight 68 lbs
Shipping Weight 82 lbs

Compatible Media

Glass bead, aluminum oxide, silicon carbide, crushed walnut shell, plastic media, soda (sodium bicarbonate). Not recommended for steel grit or steel shot at this cabinet size.

Recommended Air Compressor

Minimum 3 HP compressor with 10+ gallon tank delivering 10 CFM @ 90 PSI for continuous operation.

Applications

Small automotive parts, brake calipers, carburetors, jewelry, firearms, hand tools, small castings, electronic enclosures, and precision components requiring controlled surface preparation.
